Ubiquiti USW-Enterprise24POE Nigeria

The Ubiquiti USW-Enterprise24POE Nigeria is a fully managed, Layer 3 switch with (12) 2.5GbE, 802.3at PoE+ RJ45 ports, (12) GbE, 802.3at PoE+ RJ45 ports, (2) 10G SFP+ ports, and a 400W total PoE supply.

Description

Ubiquiti USW-Enterprise24POE Network Switch Nigeria

The Ubiquiti USW-Enterprise24POE Nigeria is a fully managed, Layer 3 switch with (12) 2.5GbE, 802.3at PoE+ RJ45 ports, (12) GbE, 802.3at PoE+ RJ45 ports, (2) 10G SFP+ ports, and a 400W total PoE supply. The USW Enterprise 24 PoE also features a 1.3″ LCM color touchscreen that concisely displays key system and connection insights.

Additionally, the Ubiquiti USW-Enterprise24POE Nigeria offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This Ubiquiti USW-Enterprise24POE Nigeria can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features

  • (1) 1.3″ LCM color touchscreen with AR switch management
  • (12) GbE, 802.3at PoE+ RJ45 ports
  • (12) 2.5GbE, 802.3at PoE+ RJ45 ports
  • (2) 10G SFP+ ports
  • (1) USP RPS DC input
  • 400W total PoE supply
  • Layer 3 switching features
  • Single-row RJ45 port layout for easy patch panel cable management

Technical Specs

Mechanical
Dimensions 442.4 x 43.7 x 325 mm (17.4 x 1.7 x 12.8″)
Weight
  • Without Mount : 5.11 kg (11.27 lb)
  • With Mount : 5.2 kg (11.46 lb)
Enclosure Materials SGCC Steel
Mount Material SGCC Steel
Hardware
Total Non-Blocking Throughput 62 Gbps
Switching Capacity 124 Gbps
Forwarding Rate 92.25 Mpps
Max. Power Consumption 550W
Power Method (1) Universal AC input: 100-240VAC, 8.5A Max., 50/60 Hz
(1) USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A
Power Supply AC/DC, Internal, 550W
Management Interface Ethernet In-Band
Networking Interfaces (12) 10/100/1000 Mbps RJ45 Ethernet
(12) 100/1000/2500 Mbps RJ45 Ethernet
SFP+ Interfaces (2) 1/10G SFP+
PoE Interfaces (24) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Max. PoE+ Wattage per Port by PSE 34.2W
Voltage Range 802.3af Mode 44 to 57V
Voltage Range 802.3at Mode 50 to 57V
Services SMB Layer 3 PoE Gigabit Ethernet Switch
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 – 95% Non-condensing
Certifications CE, FCC, IC
LEDs
System (1) Bootup Animation : Bootup in Progress
Firmware Upgrade Icon : Firmware Upgrading
Steady White : Factory Defaults, Awaiting Adoption
Steady Blue : Device is Adopted
Ethernet White : Link or Activity
SFP+ White : Link or Activity
