Ubiquiti NS-5AC Nigeria

The Ubiquiti NS-5AC Nigeria gets maximum gain out of the smallest footprint. The low cost, high-performance, and small form factor of the NS-5AC makes it extremely versatile and economical to deploy. Classic NanoStation design with updated proprietary airMAX ac chipset and dedicated management Wi-Fi for easy U Mobile app support and fast setup.

Description

Ubiquiti NS-5AC CPE Nigeria

The Ubiquiti NS-5AC Nigeria gets maximum gain out of the smallest footprint. The low cost, high-performance, and small form factor of the NS-5AC makes it extremely versatile and economical to deploy. Classic NanoStation design with updated proprietary airMAX ac chipset and dedicated management Wi-Fi for easy U Mobile app support and fast setup. Excellent solution for a simple PtP bridge or use as a PtMP station (CPE).

Features:

  • Sleek Industrial Design
    • The NanoStation AC loco represents the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.
  • Dual Ethernet Connectivity
    • The Ubiquiti NS-5AC Nigeria provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.
  • Management Wi-Fi Radio

    • Each Ubiquiti NS-5AC Nigeria model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.

  • Improved Surge Protection

    • The NanoStation AC loco feature enhanced protection against ESD events.

  • Now with airOS8

    • airOS8 provides powerful features, including airMAX ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.

Specifications

Processor Specs Atheros MIPS 74Kc, 560 MHz
Memory 64 MB DDR2
Wireless transmission speed 450+ Mbps
Operating Frequency 5GHz
Interfaces (2) 10/100/1000 Mbps Ethernet Ports
Gain 16 dBi
Polarization Dual Linear
Max. Power Consumption 8.5W
Power Supply 24V, 0.5A Gigabit PoE Supply (Included)
Power Method 802.3af Alternative A (Pairs 1, 2+; 3, 6 Return) 24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Enclosure Characteristics UV Resistant Polycarbonate
Mounting Pole Mounting Kit Included
Operating Temperature -40 to 70° C (-40 to 158° F)
Operating Humidity 5 to 95% Non-condensing
Dimensions 257 x 84 x 41 mm (10.12 x 3.31 x 1.61″)
Weight 233 g (8.22) oz
