Ubiquiti ER-X-SFP Nigeria

Rating

Ubiquiti ER-X-SFP Nigeria

The Ubiquiti ER-X-SFP Nigeria provides a graphical user interface designed for convenient setup and control. Accessed via a network port and web browser, the user provides intuitive management with a virtual view of the ports, displaying physical connectivity, speed, and status.

Description

Ubiquiti ER-X-SFP Edge Router Nigeria

The Ubiquiti ER-X-SFP Nigeria combines cost-effective routing performance with the convenience of passive PoE support in a compact form factor. Ubiquiti EdgeRouter X SFP Nigeria combines carrier-class reliability with enterprise-level features in a compact and affordable unit. Available in a rackmountable form factor with eight functional ports, the EdgeRouter Pro and 8-Port EdgeRouter models are capable of routing up to 2 million+ packets per second. Powered by a proprietary and intuitive graphical interface, EdgeOS, EdgeRouters can easily be configured for routing, security, and management features required to efficiently run your network. For advanced network professionals, an integrated CLI is available for quick and direct access using familiar commands.

Powered by a proprietary and intuitive graphical interface, EdgeOSTM, every ER-X-SFP can easily be configured for the routing, security, and management features required to efficiently run your network.

The Ubiquiti ER-X-SFP Nigeria provides a graphical user interface designed for convenient setup and control. Accessed via a network port and web browser, the user provides intuitive management with a virtual view of the ports, displaying physical connectivity, speed, and status.

Features

  • (5) Gigabit RJ45 ports with passive PoE support
  • (1) Gigabit SFP port for backhaul applications
  • Ports configurable for line-rate, Layer-2 switching
  • 130 kpps for 64-byte packets
  • 1 Gbps for 1518-byte packets

Technical Specifications

Dimensions 142 x 75 x 23 mm (5.59 x 2.95 x 0.91″)
Weight 215 g (7.58 oz)
Max. Power Consumption 5W
Power Input 24VDC, 2.5A Power Adapter (Included)
Power Supply External AC/DC Adapter
Supported Voltage Range 9 to 26VDC
Buttons Reset
LEDs Power, Link/Activity (6), PoE (5)
Processor Dual-Core 880 MHz, MIPS1004Kc
Memory 256 MB DDR3 RAM
Code Storage 256 MB NAND
Certifications CE, FCC, IC
Wall Mount Yes
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Networking Interfaces
Data/PoE Input Port (5) 10/100/1000 RJ45 Ports
Data Port (1) 100/1000 SFP Port
PoE with 24VDC Power Adapter
PoE Out Voltage Range 22-24VDC
Max. PoE Wattage Per Data Port 12W (24V)
Max. PoE Wattage Combined for All 5 Data Ports 50W
PoE Method Passive
