Tplink VIGI C400HP Nigeria

Tplink VIGI C400HP Nigeria is a Security Camera that keeps an eye on your surroundings at all times. It delivers a detailed picture of the visuals, thanks to this security camera’s up to 3 MP ultra-high-definition videos.

Category:

Description

Tplink VIGI C400HP Network Camera Nigeria

Tplink VIGI C400HP Nigeria is a Security Camera that keeps an eye on your surroundings at all times. It delivers a detailed picture of the visuals, thanks to this security camera’s up to 3 MP ultra-high-definition videos. In addition, Tplink VIGI C400HP Nigeria security camera can match your security demands with its two lens options. Tplink VIGI C400HP Nigeria has a wide-angle lens for enclosed places, like elevators, and a high-resolution lens for large distances in open regions, like parking areas.

Features

  • 3MP Ultra-High Definition: The Tplink VIGI C400HP Nigeria camera comes with 3MP–more than enough pixels to pick up some of the more discrete details.
  • 8/4mm Lens: Whether you need a wide angle lens to cover enclosed spaces or a higher millimeter lens for longer distances in open spaces, C400 comes with two different lens versions to better suit your security needs.
  • Smart Detection (motion detection, area intrusion, line-crossing, video tampering): Receive notifications and check feeds when someone crosses a boundary, enters an area you’ve set, or obstructs the camera.
  • Smart IR: Tplink VIGI C400HP Nigeria keeps objects from being under-rendered when far away or overexposed when close to camera at night.
  • WDR: Adjusts for lighting contrast to minimize shadowing effects and renders images true to life.
  • 3D DNR: Removes abnormal pixilation to provide clearer video and eliminate distortion.
  • Night Vision: A robust night vision system ensures your camera performs well in low light conditions and records what’s happening for future inspection.
  • 265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
  • PoE/12V DC: Two power supply ways not only give you more convenience but also make your wiring remarkably easy.
  • VIGI App: Manage your security from the palm of your hand with the VIGI app.

Specifications

NETWORK
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
API ONVIF
Simultaneous Live View
  • 4 Main Streams & 3 Sub-Streams,
  • or 3 Main Streams & 5 Sub-Streams
GENERAL
Package Contents
  • VIGI Network Camera
  • Quick Start Guide
  • Screws and Anchors
  • Mounting Template
Certifications CE, FCC, RCM, BSMI, VCCI, RoHS
Dimensions( H X W X D ) 123 × 123 × 83 mm
Material Plastic
Weight 195 g
General Features Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
Power Requirements
  • 12V DC ± 5%, 5.5mm Coaxial Power Plug
  • PoE (802.3af/at, class 0)
CAMERA
Image Sensor 1/2.7” Progressive Scan CMOS
Lens 2.8 mm
Aperture 2.8 mm : F2.0
Lens Mount M12
Viewing Angle horizontal FOV : 105°, vertical FOV : 56°, diagonal FOV : 125°
Day/Night Mechanism IR Cut Filter
IR Working Distance 30m
Minimum Illumination Color : 0.1 Lux@F2.0; 0 Lux with IR
Pan/Tilt Range Pan : 0° to 360°, Tilt : 0° to 85°, Rotate : 0° to 360°
Digital Noise Reduction 3D DNR
WDR DWDR
VIDEO/IMAGE
Video Compression
  • Main stream : H.265/H.264
  • Sub-Stream : H.265/H.264
Frame Rate & Resolutions
  • Frame Rate : 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution : 2304×1296, 2048×1280, 1920×1080, 1280×720, 704×576, 640×480, 352×288, 320×240
Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
Image Enhancement BLC/3D DNR/Prevent Overexposure to Infrared Light
Video Bit Rate 64 Kbps to 6 Mbps
SMART FEATURE-SET
Smart Event Area Intrusion Detection, Line-Crossing Detection
Basic Event Motion Detection, Video Tampering Detection, Exception ( illegal login)
Linkage Method Trigger Notification : ONVIF, HTTPS
Region of Interest 1 Region
INTERFACES
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port
Button
Video Output
