Tplink TL-WA901N Nigeria

Rating

Tplink TL-WA901N Nigeria

The Tplink TL-WA901N Nigeria is a Wireless N Access Point is designed to establish or expand a scalable high-speed wireless N network or to connect an Ethernet-enabled device such as a game console, digital media adapter, printer, or network-attached storage device to a wireless network.

Description

Tplink TL-WA901N Access Point Nigeria

The Tplink TL-WA901N Nigeria is a Wireless N Access Point is designed to establish or expand a scalable high-speed wireless N network or to connect an Ethernet-enabled device such as a game console, digital media adapter, printer, or network-attached storage device to a wireless network. The Tplink TL-WA901N Nigeria supports a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or any other application that you may wish to use.

Features

  • 450Mbps wireless transmission rate brings smooth wireless N experience
  • Supports multiple operating modes: Access Point, Range Extender, Multi-SSID and Client modes
  • Easily setup a WPA-PSK/WPA2-PSK encrypted secure connection at a push of the 21WPS button
  • Up to 30 meters (100 feet) of flexible deployment with included Power over Ethernet Injector

Wireless N Speed & Range

Tplink TL-WA901N Nigeria adopts IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through three antennas with smart antenna technology to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building.

Multiple Operating Modes

Tplink TL-WA901N Nigeria Access Point Supports Client, Multi-SSID, Range Extender, and AP operation modes to enable various wireless applications to give users a more dynamic and comprehensive experience when using your AP. Multiple operating mode also helps you easily build wireless network for hard-to-wire locations or eliminating wireless dead zone.

Passive PoE Supported

The Tplink TL-WA901N Nigeria is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.

Specifications

HARDWARE FEATURES
Interface 1× 10/100M Ethernet Port(RJ45)
Support Passive PoE
Button Power On/Off Button, Reset Button, WPS Button
External Power Supply 9VDC / 0.85A
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 7.7 × 5.3 × 1.4 in (195 × 134 × 36 mm )
Antenna Type 3 Fixed Omni-Directional Antennas
WIRELESS FEATURES
Frequency 2.4 GHz
Signal Rate 450 Mbps at 2.4 GHz
Reception Sensitivity
  • 11g 54M: -76dBm
  • 11n 20Mbps: -73dBm
  • 11n 40Mbps: -70dBm
Transmit Power CE: <20dBm; FCC: <30dBm
Wireless Modes Access Point, Range Extender, Client, Multi-SSID
Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryptions
DHCP Server, DHCP Client List
Quality of Service WMM
Management SNMP
Advanced Functions Up to 30 meters PoE is supported
OTHERS
Certification CE, FCC, RoHS
Package Contents
  • Wireless N Access Point TL-WA901N
  • Power Adapter
  • Passive PoE Power Injector
  • RJ45 Ethernet Cable
  • Quick Installation Guide
System Requirements
  • Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
  • NetWare, UNIX or Linux
  • Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
  • Java-enabled browser
  • Cable or DSL Modem
  • Subscription with an Internet Service Provider (for Internet access)
Environment
  • Operating Temperature: 0°C~40°C (32°F~104°F)
  • Storage Temperature: -40°C~70°C (-40°F~158°F)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
Protocol Support IPv4, IPv6
