Tplink TL-POE150S Nigeria

The Tplink TL-POE150S Nigeria PoE Injector fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PDs (Powered Devices) or PoE Receiver Adapters

Category:

Description

Tplink TL-POE150S PoE Injector Nigeria

The Tplink TL-POE150S Nigeria PoE Injector fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PDs (Powered Devices) or PoE Receiver Adapters, such as TP-LINK’s TL-POE10R, or other equivalent product, to expand your network to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc.

Features

  • Gigabit speed support
  • Complies with IEEE802.3af standard
  • Delivers power and data over the single cable up to 100 meters
  • Cost Saving, no power cabling for Ethernet network device
  • Advanced Auto-Sensing Algorithm enables providing power with 802.3af PD
  • Supports power classi­fication, Auto-determine the necessary power requirements
  • High Safety with Short Circuit Protection
  • Plug & Play installation, requires no confi­guration
  • External 48VDC power supply

Specifications

Hardware Features
Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Interface
  • 2 10/100/1000Mbps RJ45 Port
  • AUTO Negotiation/AUTO MDI/MDIX
  • 1 48VDC Power Input Port
Forwarding Rates
  • 10BASE-T : UTP category 3, 4, 5 cable (Max 100m)
  • EIA/TIA-568 100Ω STP (Max 100m)
  • 100BASE-TX : UTP category 5, 5e cable (Max 100m)
  • EIA/TIA-568 100Ω STP (Max 100m)
  • 1000BASE-T : UTP category 5, 5e, 6 cable (Max 100m)
Power Supply 15.4W (Max. 48VDC)
Basic Function
  • Compatible With IEEE 802.3af Compliant PSEs
  • Delivers Power Up To 100 Meters
  • Optional 12VDC, 9VDC or 5VDC Power Output
LED Indicator PWR
Dimensions ( W x D x H ) 3.2 x 2.1 x 0.9 in. (80.8 x 54 x 24 mm)
Software Features
Advanced Features
  • Compatible With IEEE 802.3af Compliant PDs
  • Delivers Power Up To 100 Meters
  • Auto-Determine The Necessary Power Requirements
Others
Certification CE, FCC, RoHS
Package Contents
  • TL-POE150S PoE Injector
  • One Ethernet (CAT.5 UTP) Cable
  • One Power Adapter
  • User Guide
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux.
Environment
  • Operating Temperature : 0°C~40°C (32°F~104°F),
  • Storage Temperature : -40°C~70°C (-40°F~158°F)
  • Operating Humidity : 10%~90% non-condensing,
  • Storage Humidity : 5%~90% non-condensing

Datasheet Download
