Tplink TL-PA4020P KIT Nigeria

Rating

Tplink TL-PA4020P KIT Nigeria

The Tplink TL-PA4020P KIT Nigeria Powerline Adapter transforms your home’s existing electrical circuit into a high speed network. No configuration is required — plug your adapter into a power socket and establish a connection within minutes.

Description

Tplink TL-PA4020P KIT Powerline Adapter Nigeria

The Tplink TL-PA4020P KIT Nigeria Powerline Adapter transforms your home’s existing electrical circuit into a high speed network. No configuration is required — plug your adapter into a power socket and establish a connection within minutes.  Tplink TL-PA4020P KIT Nigeria HomePlug-AV500 2-Port Powerline Adapter Starter Kit from TP-Link features two Ethernet ports and one power socket. The dual Ethernet ports allow you to connect two Ethernet compatible devices directly to your network.

Tplink TL-PA4020P KIT Nigeria allow you take advantage of data transfer rates of up to 500 Mbps at wire distances of up to 984′ (300 m). You will also find an integrated power socket on each adapter keeping your electrical outlet free. Tplink TL-PA4020P KIT Nigeria setup is simple, as all you have to do is plug in the Internet connected adapter to an outlet and plug in the other adapter to an outlet where you need an Internet connection. The integrated pairing button does the rest creating a high speed, encrypted network connection.

Features

  • HomePlug AV standard compliant, providing data transmission over electrical wires for HD video streaming
  • Integrated power socket ensures that no power outlet goes to waste
  • Plug and play design and easy encryption at a push of the pair button
  • Power-Saving Mode automatically reduces power consumption by up to 85%

Maximum Speeds and 300 Meter Range

Using advanced Home Plug AV technology, Tplink TL-PA4020P KIT Nigeria provides stable, ultra-high-speed data transfer rates over a household electric circuit for up to 300 meters. TL-PA4020P KIT easily handles bandwidth intensive applications. Stream in HD, game online and download large files without interruption thanks to reliable powerline links.

Pair Button for Easy Network Security

You can set up a powerline network within minutes with TP-LINK’s powerline adapters, just plug in and play. Also, the adapters’ “Pair” buttons can be utilized for securing or managing multiple powerline adapters in your home powerline network.

  • Plug one Internet connected adapter into a nearby power outlet.
  • Connect additional adapters to PCs/laptops/Internet TVs or other networked devices via an Ethernet cable or Wi-Fi and you’re done.

Power Socket for Additional Devices

With its integrated power socket, Tplink TL-PA4020P KIT Nigeria provides ultimate convenience for your home. Connect an additional device or power strip to the adapter as though it were a normal wall socket.

Two LAN Ports

Compared with TL-PA4010P KIT, TL-PA4020P KIT is equipped with an additional LAN port to give you more wired network connections. Link two devices to the adaptor via Ethernet cables to enjoy fast, simultaneous wired internet on both.

Mains Filter for Better Performance

With its Integrated Mains Filter, Tplink TL-PA4020P KIT Nigeria can optimize powerline communication performance by suppressing noise interference generated by surrounding electronic equipment that can affect network performance. That means that users won’t experience a sudden speed drop when a larger power-consuming device is plugged into the power socket.

Saves Up to 85% on Power

Tplink TL-PA4020P KIT Nigeria automatically switches from its regular working more to efficient Power-Saving mode when not in use, reducing energy consumption by up to 85%.

Specifications

HARDWARE FEATURES
Plug Type EU, UK, FR, US
Standards and Protocols HomePlug AV, IEEE802.3, IEEE802.3u
Interface 2* 10/100Mbps Ethernet Ports, Power Socket
Button Pair Button
Power Consumption
  • Maximum : 5.82W (220V/50Hz)
  • Typical : 5.20W (220V/50Hz)
  • Standby : 0.92W (220V/50Hz)
LED Power, Powerline, Ethernet
Dimensions ( W x D x H ) 3.7 x 2.3 x 1.7 in. (95 x 58 x 42 mm)
Range 300 meters over a single circuit
SOFTWARE FEATURES
Modulation Technology OFDM
Encryption 128-bit AES Encryption
OTHERS
Certification CE, FCC, RoHS
Package Contents
  • Powerline Ethernet Adapter *2
  • Ethernet cable (RJ45) *2
  • Resource CD
  • Quick Installation Guide
System Requirements Windows 8/7/Vista/XP/2000, Mac OS, Linux*
Environment
  • Operating Temperature : 0°C~40°C (32°F~104°F)
  • Storage Temperature : -40°C~70°C (-40°F~158°F)
  • Operating Humidity : 10%~90% non-condensing
  • Storage Humidity : 5%~90% non-condensing



Datasheet Download
