Description
Tplink TL-FC111B20 Media Converter Nigeria
The Tplink TL-FC111B20 Nigeria is a 100M media converter, providing a 100M RJ-45 port and a 100M SC fiber port, which can convert between electrical and optical signals. And long-distance data transmission through optical fiber can be applied to commercial scenarios such as park security monitoring and wireless networking. Tplink TL-FC111B20 Nigeria adopts WDM (wavelength division multiplexing) technology, helping send and receive data at a distance of up to 20km (12.4 miles) over only one fiber, which saves half of the cable deployment cost for customers. Tplink TL-FC111B20 transmits data at 1310nm wavelength and receives data at 1550nm wavelength on optical fiber. The Tplink TL-FC111B20 works in the other end as a pair by receiving data at a wavelength 1310nm and sending data at wavelength 1550nm.
Features
- Complies with 802.3u 10/100Base-TX, 100Base-FX standards
- Auto-negotiation of Half-Duplex/Full-Duplex transfer mode
- 9/125 μm SMF (Single-Mode Fiber)
- Bidirectional WDM communication on a single fiber
- Ranges up to 20km (12.4 miles)
- Work with TL-FC111B20 as a pair
Specifications
NETWORK | |
Standards and Protocols | IEEE802.3, IEEE802.3i, IEEE802.3u |
ENVIRONMENT | |
Operating Temperature | 0˚C to 50˚C (32˚F to 122˚F) |
Storage Temperature | -40˚C to 70˚C (-40˚F to 158˚F) |
Operating Humidity | 10% to 90% RH non-condensing |
Storage Humidity | 5% to 90% RH non-condensing |
HARDWARE FEATURES | |
Network Media | 100BASE-Tx: 2-pair UTP/STP of Cat. 5 or above (≤100 m) |
Power Supply | External Power Adapter: 5 V/0.6 A |
LED | PWR, Link/Act |
Dimensions ( W x D x H ) | 94.5*73*27 mm |
Wave Length | 1310 nm TX, 1550 nm RX |
ANTENNA | |
Connector Type | 1 SC fiber optic, 1 RJ45 jack |
MEDIA CONVERTER & MODULE | |
Fiber Type | 9/125 μm single-mode fber (≤20 km) |
