Tplink Archer-AX20 Nigeria

Rating

Tplink Archer-AX20 Nigeria

The Tplink Archer-AX20 Nigeria is the latest generation of Wi-Fi 6 Experience brings faster speeds, less lag, and higher capacity, enabling more simultaneous connections on your home network.

Description

Tplink Archer-AX20 Router Nigeria

The Tplink Archer-AX20 Nigeria is the latest generation of Wi-Fi 6 Experience brings faster speeds, less lag, and higher capacity, enabling more simultaneous connections on your home network. Tplink Archer-AX20 Nigeria has Dual-Band Wi-Fi 6 Up to 1.8 Gbps making every application feels more fluid with drastically improved WiFi speeds. Both 2.4 GHz band and 5 GHz band get upgraded to the latest generation—perfect for 4K streaming, online gaming, and fast downloading.

With extensive WiFi Coverage with Advanced Technologies, independent Front-End Module, and four high-gain antennas Tplink Archer-AX20 Nigeria adapts WiFi coverage to perfectly fit your home and concentrate signal strength towards your devices.

Tplink Archer-AX20 Nigeria easily handle dozens of devices streaming and gaming at the same time—OFDMA future-proofs your home networks by providing greater capacity to connect more devices. The Tplink Archer-AX20 Nigeria latest WiFi security protocol, WPA3, brings new capabilities to improve cybersecurity in personal networks. More secure encryption in WiFi password safety and enhanced protection against brute-force attacks combine to safeguard your home WiFi.

Features

  • Dual-Band Wi-Fi 6: Wi-Fi 6 technology achieves faster speeds, greater capacity and reduced network congestion compared to the previous generation.
  • Next-Gen 1.8 Gbps Speeds: Enjoy smoother and more stable streaming, gaming, downloading and more with WiFi speeds up to 1.8 Gbps (1200 Mbps on 5 GHz band and 574 Mbps on 2.4 GHz band).
  • Connect More Devices:  Wi-Fi 6 technology communicates more data to more devices using revolutionary OFDMA technology while simultaneously reducing lag for ultra-responsive entertainment.
  • Quad-Core Processing: The powerful 1.5 GHz quad-core CPU ensures communications between your router and connected devices are smooth.
  • Extensive Coverage: Achieve the strongest, most reliable WiFi coverage with Archer AX1800 as it focuses signal strength to your devices far away using Beamforming technology, 4 antennas and an advanced front-end module (FEM) chipset.
  • Increased Battery Life for Devices: Target Wake Time technology reduces your devices’ power consumption to extend their battery life.
  • Easy Setup: Set up your router in minutes with the powerful TP-Link Tether App
  • Backward Compatible: Archer-AX20 supports all previous 802.11 standards and all WiFi devices

Specifications

WIRELESS
Standards
  • Wi-Fi 6
  • IEEE 802.11ax/ac/n/a 5 GHz
  • IEEE 802.11ax/n/b/g 2.4 GHz
WiFi Speeds
  • AX1800
  • 5 GHz: 1201 Mbps (802.11ax)
  • 2.4 GHz: 574 Mbps (802.11ax)
WiFi Range
  • 3 Bedroom Houses
  • 4× Fixed High-Performance Antennas
    Multiple antennas form a signal-boosting array to cover more directions and large areas
  • Beamforming
    Concentrates wireless signal strength towards clients to expand WiFi range
  • High-Power FEM
    Improves transmission power to strengthen signal coverage
WiFi Capacity
  • High
  • Dual-Band
    Allocate devices to different bands for optimal performance
  • OFDMA
    Simultaneously communicates with multiple Wi-Fi 6 clients
  • Airtime Fairness
    Improves network efficiency by limiting excessive occupation
  • 4 Streams
    Connect your devices to more bandwidth
Working Modes
  • Router Mode
  • Access Point Mode
HARDWARE
Processor 1.5 GHz Quad-Core CPU
Ethernet Ports
  • 1× Gigabit WAN Port
  • 4× Gigabit LAN Ports
USB Support 1× USB 2.0 Port

Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32

Supported Functions:

  • Apple Time Machine
  • FTP Server
  • Media Server
  • Samba Server
Buttons
  • WPS/Wi-Fi Button
  • Power On/Off Button
  • LED On/Off Button
  • Reset Button
Power 12 V ⎓ 1.5 A
SECURITY
WiFi Encryption
  • WPA
  • WPA2
  • WPA3
  • WPA/WPA2-Enterprise (802.1x)
Network Security
  • SPI Firewall
  • Access Control
  • IP & MAC Binding
  • Application Layer Gateway
Guest Network
  • 1× 5 GHz Guest Network
  • 1× 2.4 GHz Guest Network
VPN Server
  • OpenVPN
  • PPTP
SOFTWARE
Protocols
  • IPv4
  • IPv6
OneMesh™ OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Parental Controls
  • URL Filtering
  • Time Controls
WAN Types
  • Dynamic IP
  • Static IP
  • PPPoE
  • PPTP
  • L2TP
Quality of Service QoS by Device
Cloud Service
  • Auto Firmware Upgrade
  • OTA Firmware Upgrade
  • TP-Link ID
  • DDNS
NAT Forwarding
  • Port Forwarding
  • Port Triggering
  • DMZ
  • UPnP
IPTV
  • IGMP Proxy
  • IGMP Snooping
  • Bridge
  • Tag VLAN
DHCP
  • Address Reservation
  • DHCP Client List
  • Server
DDNS
  • TP-Link
  • NO-IP
  • DynDNS
Management Tether App
PHYSICAL
Dimensions (W×D×H) 10.2 × 5.3 ×1.5 in
(260.2 × 135.0 × 38.6 mm)
Package Contents
  • Wi-Fi Router Archer-AX20
  • Power Adapter
  • RJ45 Ethernet Cable
  • Quick Installation Guide
OTHER
System Requirements
  • Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
  • Cable or DSL Modem (if needed)
  • Subscription with an internet service provider (for internet access)
Certifications FCC
Environment
  • Operating Temperature: 0℃~40℃ (32℉ ~104℉)
  • Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power FCC:
<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz)
WiFi Reception Sensitivity 5 GHz:

  • 11a 6Mbps:-97dBm
  • 11a 54Mbps:-79dBm
  • 11ac VHT20_MCS0:-96dBm
  • 11ac VHT20_MCS11:-66dBm
  • 11ac VHT40_MCS0:-94dBm
  • 11ac VHT40_MCS11:-63dBm
  • 11ac VHT80_MCS0:-91dBm
  • 11ac VHT80_MCS11:-60dBm
  • 11ax HE20_MCS0:-95dBm
  • 11ax HE20_MCS11:-63dBm
  • 11ax HE40_MCS0:-92dBm
  • 11ax HE40_MCS11:-60dBm
  • 11ax HE80_MCS0:-89dBm
  • 11ax HE80_MCS11:-58dBm

2.4 GHz:

  • 11g 6Mbps:-97dBm
  • 11n HT20_MCS0:-97dBm
  • 11n HT20_MCS7:-78dBm
  • 11n HT40_MCS0:-95dBm
  • 11n HT40_MCS7:-75dBm
  • 11ac VHT20_MCS0:-96dBm
  • 11ac VHT20_MCS11:-67dBm
  • 11ac VHT40_MCS0:-94dBm
  • 11ac VHT40_MCS11:-64dBm
  • 11ax HE20_MCS0:-96dBm
  • 11ax HE20_MCS11:-64dBm
  • \11ax HE40_MCS0:-93dBm
  • 11ax HE40_MCS11:-61dBm
