Ruijie rg-rap1200f Nigeria

Rating

Ruijie rg-rap1200f nigeria

The Ruijie rg-rap1200f nigeria dual-band FE wall plate AP is a high-performance wall plate AP. With 802.3af/at PoE support, the AP provides a LAN port at the front to facilitate the expansion of IPTV, IP phone, etc.

Description

Ruijie rg-rap1200f access point nigeria

The ruijie rg-rap1200f nigeria dual-band FE wall plate AP is a high-performance wall plate AP. With 802.3af/at PoE support, the AP provides a LAN port at the front to facilitate the expansion of IPTV, IP phone, etc. Compliant with 802.11a/b/g/n/ac Wave1/Wave2 Wi-Fi protocol, ruijie rg-rap1200f nigeria supports MU-MIMO dual-stream technology and offers built-in omnidirectional antennas. It can operate concurrently at 2.4GHz and 5GHz, providing high-speed wireless access of 400Mbps at 2.4GHz, 867Mbps at 5GHz and up to 1267Mbps per AP. Featuring compact 86mm wall plate installation design ruijie rg-rap1200f nigeria, facilitates quick installation directly into a standard 86mm wall junction box, which is an ideal choice for deployment such as offices, commercial industry, hotels, service scenarios, etc.

The AP supports Ruijie’s self-organizing network feature, which means to realizes auto-discovery, auto-networking and auto-configuration between routers, switches, and wireless APs without the need for controllers or Internet access. With the Ruijie Cloud app, users can quickly complete the device deployment and configuration, remote management, operation and maintenance of the entire network, which greatly reduces the investment of equipment cost, labor cost and time cost in the process of wireless network construction.

Ruijie Rg Rap1200f Accesspoint Nigeria

Ruijie Rg Rap1200f Accesspoint Nigeria

Features

  • 11ac Wave2 technology
  • Auto-provisioning via Self-Organizing Network : Supports Ruijie’s self-developed smart networking feature, which breaks through the product limitations and realizes auto-discovery, auto-networking and auto-configuration between gateways, switches, and wireless APs without the need for controllers or Internet access;
  • Lifetime free Ruijie Cloud management : Remote fault alarm, one-click optimizing and maintenance on Ruijie Cloud App;
  • Seamless layer 3 roaming
  • Industrial Design : Robust casing, Provide better strength and safety for products;
  • High-speed dual-band Wi-Fi
  • Support routing and AP mode
  • Support Layer 3 networking
  • Stronger and more stable signals
  • Multi-way management
  • Remote collaborative management
  • Al & big data network optimization

Specifications

Hardware specifications
Radio Dual-stream dual-band
Protocol Concurrent 802.11b/g/n/ac
Operating Bands
  • 802.11b/g/n : 2.4G ~ 2.4835GHz
  • 802.11a/n/ac : 5G : 5.150~5.350GHz,5.47~5.725,5.725~5.850GHz
Antenna PCB antenna
Spatial Streams
  • 2.4G : 2 Spatial Streams,2×2 MIMO
  • 5G : 2 Spatial Streams,2×2 MIMO
Max Throughput
  • 2.4G : up to 400Mbps
  • 5G : up to 866.7Mbps
Modulation
  • OFDM : BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
  • DSSS : DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
  • MIMO-OFDM : BPSK, QPSK, 16QAM, 64QAM and 256QAM
Receive Sensitivity
  • 11b : -97dBm(1Mbps) ,-92dBm(5Mbps) ,-89dBm(11Mbps)
  • 11a/g : -94dBm(6Mbps),-85dBm(24Mbps),-82dBm(36Mbps),-76.5dBm(54Mbps)
  • 11n : -93.5dBm@MCS0,-74dBm@MCS7,-74dBm@MCS15
  • 11ac : HT20 : -92.5dBm(MCS0), -68.5dBm(MCS8)
  • 11ac : HT40 : -89dBm(MCS0), -64dBm(MCS9)
  • 11ac : HT80 : -86dBm(MCS0), -60.5dBm(MCS8)
Maximum Transmit Power 20dBm (adjustable)
Adjustable Power 1dBm
Dimensions 86*86*29.3
Weight <0.25kg
Service Ports Front :

  • 1 10/100Mbps Ethernet portRear :
  • 1 10/100Mbps PoE Ethernet port
Management Port N/A
LED Indicator Support
Power Supply Support 802.3af power supply
Power Consumption <8W
Environment Operating temperature : 0°C~40°C
Storage temperature : -40°C~70°C
Operating humidity : 5%~95%(non-condensing)
Storage humidity : 5%~95%(non-condensing)
Installation 86mm wall plate installation
IP Rating IP41
Safety Standard GB4943, IEC62368-1
EMC Standard GB9254,EN301 489,EN50155,EN50121,EN55032,EN61000,EN55035
Vibration Standard IEC61373
Radio Standard EN300 328, EN301 893
Software Features
Operating Mode AP mode and routing mode
WLAN Maximum number of clients : 110
Recommended number of clients : 40 (8 at 2.4GHz, 32 at 5GHz)
Up to 8 SSIDs
  • Support SSID hiding
  • Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID
SSID-based and radio-based STA limit
Support Layer 2 user isolation
Roaming Support Layer 2 and Layer 3 roaming
Security Support PSK authentication
Support static blacklist and whitelist
Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption
Routing Support static IP address, DHCP, PPPoE Dial Up
Management and maintenance
  • Support unified networking of all network equipment
  • Support local or remote management with Ruijie Cloud app
  • Support local management with web
  • Support remote management with Ruijie Cloud platform
Platform management features Automatic RF adjustment via the platform
Unified configuration via the platform
Unified monitoring via the platform



Datasheet Download
