Ruijie rg-es224gc Nigeria

Rating

Ruijie rg-es224gc nigeria

The Ruijie rg-es224gc nigeria is a 24-Port Gigabit Cloud Managed Non-PoE Switch featuring 24-Port Gigabit Managed Non-PoE Switch. This Gigabit access PoE switch fits needs in SMB network.

Description

Ruijie rg-es224gc network switch  nigeria

The ruijie rg-es224gc nigeria is a 24-Port Gigabit Cloud Managed Non-PoE Switch featuring 24-Port Gigabit Managed Non-PoE Switch. This Gigabit access PoE switch fits needs in SMB network.  Featuring Cost-Effective Smart Cloud Managed Switch ruijie rg-es224gc nigeria, is designed specifically for Enterprise scenarios, Hospitality, Factory, Education, Retails, Surveillance. The switch adopts a light-weighted Cloud management design, providing faster response to support richer features.

Features

  • 24-Port gigabit cloud managed non-PoE switch
  • Cost-Effective Smart Cloud Managed Switches
  • IP Camera Recognition, Unique Value for CCTV Network
  • Automatic Loop Prevention Ensures Service Continuity
  • Lifetime management on Ruijie Cloud anytime anywhere

Plug and Play with zero configuration

Under factory default state, ruijie rg-es224gc nigeria require zero configuration after plugged in. The video surveillance network can be set up quickly after connecting the switch to the cameras and DVR correctly.

High compatibility for network cable

The smart surveillance ruijie rg-es224gc nigeria not only support standard cat5/5e/6 network cables, but also support data transmission via network cables of non-standard materials (such as 0.38/0.40/0.45-diameter copper-clad steel/iron), facilitating the construction and cabling.

High surge protection for device stability

The ports of the smart surveillance switches offer surge protection of up to 6KV, reducing the probability of being damaged by the surge and improving the stability of the customer’s network.

Fast fault positioning

The ruijie rg-es224gc nigeria supports network topology display of the entire network and monitoring the network status in real time. When failure occurs for the network camera, the location and cause of failure can be displayed in a timely manner, and the notification can be sent via the mobile app.

On-demand VLAN configuration

In the network of villas/ stores/ offices, the network cameras and wireless APs may be connected to the same switch. Without network isolation, there may be problems such as camera screen lag and slow wireless speed. The smart surveillance switches provide convenient and flexible VLAN division, which can automatically divide different VLANs according to the type of equipment connected to the port, so that the surveillance network and data network do not interfere with each other, improving the stability of the entire network.

Ruijie Cloud app/ Ruijie Cloud platform remote management

The ruijie rg-es224gc nigeria not only support web interface management, but also support mobile app and Ruijie Cloud platform remote management. Users can view the network status, modify the configuration, and troubleshoot at home. In addition, the ports can be restarted remotely.

Auto-networking for switches allowing one-step project management

The smart surveillance switches can obtain the IP address automatically from the gateway and connect to the external network without configuration. MANET for switches is also supported. Users can scan the QR code of any switch in the network using the mobile app to automatically add all switches in the network to the project. In addition, the smart surveillance switches support networking with Reyee Series EG / EAP. The switches can be automatically discovered by the Reyee Series EG / EAP and added to the corresponding project.

Specifications

Hardware specifications
Ports 24 10/100/1000Base-T ports
Switching capacity 48Gbps
Package forwarding rate 36Mpps
Surge protection Common mode : 6KV
Power consumption <14W
Power supply Built-in power supply
Dimensions (W x D x H) 440x165x44mm
MTBF >200K
Operating environment
Operating temperature 0 to 50°C
Storage temperature -40~70ºC
Operating humidity 10% to 90% RH
Storage humidity 5% to 95% RH
Software features
MAC capacity 8K
Static MAC address 16
VLAN Support 802.1Q VLAN
Port management Support port status display, port traffic statistics, port duplex / negotiation rate configuration, flow control configuration
Security Support broadcast storm suppression, port speed limit, port isolation, DHCP Snooping
L2 features Support port mirroring, loop protection, cable detection
Management Support management and configuration through web management interface, Ruijie Cloud platform and Ruijie Cloud
