Hardware |
CPU |
Dual Core Intel Core i3-2120 Processor 3.3 GHz |
DRAM |
2 GB DDR3 RAM |
Flash Memory |
512 MB DOM |
Hard Drive |
- 8x 3.5″ (88.89 mm) SATA 6 GBps, SATA 3 GBps hard drive or 2.5″ (63.49 mm) SATA, SSD hard drive*
- Hard Drive Trays : 8x hot-swappable and lockable
|
LAN Port |
- 2x Gigabit RJ-45 Ethernet ports
- Optional dual-port 10 GbE and 1 GbE network cards are supported
|
USB |
- 2x USB 3.0 ports (rear)
- 4x USB 2.0 ports (rear)
- Supports USB printer, pen drive, USB hub, USB UPS and many more
|
eSATA |
2 (rear) |
LED Indicators |
Status, 10 GbE, LAN, eSATA, hard drives |
Buttons |
System : Power button and reset button |
LCD Panel |
- Mono-LCD display with backlight
- Enter and select buttons for configuration
|
Expansion Slot |
2x : For network or storage expansion |
VGA |
Reserved for system maintenance |
Fan |
3x 2.4″ (6.0 cm) smart cooling fan |
Alarm |
Buzzer for system warning |
Sound Level |
- With 8x 1 TB hard drives installed :
- Standby : 54.57 dB
- In operation : 54.6 dB
|
Power Consumption |
- With 8x 1 TB hard drives installed :
- Sleep mode : 68 W
- In Operation : 130 W
|
Power Supply |
- Input : 100 – 240 V AC, 47 – 63 Hz
- Output : 300 W
|
Form Factor |
2U, rackmount** |
Software |
Operating System |
Embedded Linux |
Supported Operating System |
- Windows XP, Vista, Windows 7 (32/64-bit), Windows Server 2003/2008 R2
- Apple Mac OS X
- Linux and UNIX
|
Supported Web Browsers |
- Microsoft Internet Explorer 8, 9
- Mozilla Firefox 8, 9, 10
- Apple Safari 4, 5
- Google Chrome
|
Multilingual Support |
Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish |
File System |
- Internal Hard Drive : EXT3, EXT4
- External Hard Drive : EXT3, EXT4, NTFS, FAT32, HFS+
|
Networking |
- TCP/IP (IPv4 and IPv6 : Dual stack)
- Multiple Gigabit NICs with jumbo frame
- Failover
- Multi-IP settings
- Port trunking/NIC teaming (Modes : Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
- Service binding based on network interfaces
- Virtual LAN (VLAN)
- DHCP client, DHCP server
- Protocols : CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP and SMSC
- UPnP and bonjour discovery
- USB Wi-Fi adapter support
|
Backup Solution |
- Real-Time Remote Replication (RTRR)
- Works as both RTRR server and client with bandwidth control
- Real-time and scheduled backup
- Encryption, compression, file filter and transfer rate limitation
- Block-Level Remote Replication
- Works as both Rsync Server and client with bandwidth control
- Encrypted replication between QNAP NAS servers
- One touch backup (import/export) via USB
- Desktop backup by QNAP NetBak replicator for Windows
- Apple Time Machine support with backup management
- Data backup to multiple external storage devices
- Data backup to Cloud Storage (Amazon S3, ElephantDrive and Symform)
|
Security |
- IP Filter and policy-based automatic IP blocking
- Network access protection with auto-blocking : SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
- Encrypted Access : HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), encrypted remote replication between QNAP NAS servers (Rsync over SSH)
- CIFS host access control for shared folders
- Antivirus protection
- FIPS 140-2 validated AES 256-bit volume-based data encryption*
- AES 256-bit external drive encryption*
- Importable SSL certificate
- Instant alert via email, SMS, instant messaging (Windows Live Messenger) and buzzer
|
Disk Management |
- Single Disk, JBOD, RAID 0, 1, 5, 5 + Hot-Spare, 6, 6 + Hot-Spare, 10, 10 + Hot-Spare
- Online RAID capacity expansion and online raid level migration
- Bad block scan and hard drive S.M.A.R.T.
- Global hot-spare drive
- RAID recovery
- Bitmap support
|
iSCSI (IP SAN) |
- iSCSI target
- Multi-LUNs per target
- Up to 256 targets/LUNs combined
- Supports LUN mapping and masking
- Online LUN capacity expansion
- Supports SPC-3 persistent reservation
- Supports MPIO and MC/S
- iSCSI LUN backup, one-time snapshot and restore
- iSCSI connection and management by QNAP finder (Windows)
- Virtual disk drive (via iSCSI initiator)
- Stack chaining master
- Max. no. of virtual disk drives : 8
|
Server Virtualization and Clustering |
- Supports VMware vSphere
- Supports Citrix XenServer
- Supports Windows Server 2008 R2 Hyper-V and failover clustering
|
Power Management |
- Wake on LAN
- Internal hard drive standby mode
- Scheduled power on/off (max. 15 Settings)
- Automatic power on after power recovery
- USB and network UPS support with SNMP management
|
Access Rights Management |
- Max. No. of Users : 4,096
- Max. No. of User Groups : 512
- Max. No. of Network Shares : 512
- Batch users creation
- Import/export users
- User quota management
- Subfolder permissions support for CIFS/SMB, AFP, FTP and web file manager
|
Domain Authentication Integration |
- Microsoft Active Directory (AD)
- LDAP server
- LDAP client
- Domain users login via CIFS/SMB, AFP, FTP and web file manager
|
MyCloudNAS Service |
- Private Cloud Storage and sharing
- Free host name registration (DDNS)
- Auto router configuration (via UPnP)
- MyCloudNAS connect for easy connection (Windows utility)
|
Storage Plug & Play |
- Windows Software : QNAP finder
- Create and map shared folders
- Create and connect to iSCSI target/LUN
|
Web Administration |
- AJAX-based user interface
- Smart fan control
- Dynamic DNS (DDNS)
- SNMP (v2 and v3)
- Resource monitor
- Network recycle bin for file deletion via CIFS/SMB and AFP
- Comprehensive logs (Events and connection)
- Syslog client
- Firmware live update
- System settings backup and restore
- Restore to factory default
|
Powerful All-in-one server |
File Server |
- File sharing across Windows, Mac and Linux or UNIX
- Shared folder aggregation (CIFS/SMB)
- Web file manager
- Supports ISO mounting
- Direct file viewing via Google doc
- Create and send download links for public file sharing with expiration time and password protection
|
FTP Server |
- FTP over SSL/TLS (explicit)
- Max. No. of Concurrent Connections : 256
- FXP supported
- Passive FTP port range control
- FTP bandwidth and connection control
- Unicode support
|
Backup Server |
- Remote Replication server (over Rsync)
- Real-Time Remote Replication to another QNAP NAS or FTP server
- Apple Time Machine support
- Windows Client Backup Application : QNAP NetBak replicator
- Third Party Backup Software Support : Acronis True Image, CA BrightStor, ARCserve, Backup, EMC Retrospect, Symantec Backup Exec, LaCie SilverKeeper and more
|
Web Server |
- HTTP/HTTPS connections
- Supports WebDAV connection
- Support virtual host (Max. : 32)
- Importable SSL certificate
|
Database Server |
- Built-in MySQL server (v5.1.36)
- Web-based management via phpMyAdmin (QPKG)
|
Print Server |
- Max. Number of Printers : 3
- Supports Internet printing protocol
- Print job display and management
- IP- and domain name based privilege control
- Supports Apple bonjour printing
|
Syslog Server |
- Centralized log monitoring and archiving
- Immediate email alerts
- Supports log filtering
|
RADIUS Server |
- Centralized account management and authentication for network access
- Supports 802.1x security authentication
- TFTP server with PXE booting (read-only)
|
VPN Server |
- Secure Remote Access : PPTP and OpenVPN services
- Remote access to other resources on local network
- Max. No. of Clients : 30
|
iTunes Server |
- Audio and video sharing (AIF, M4A, M4B, M4V, MOV, MP1, MP2, MP3, MP4, MPEG, MPG, WAV)
- Smart playlist for iTunes client (Windows and Mac OS)
|
UPnP Media Server |
- Built-in TwonkyMedia server
- Real-time and background photo transcoding
- Supports UPnP media player such as PlayStation 3 and Xbox 360
- Supported format (The actual playback capabilities may vary depending on the UPnP client.)
- Audio : MP3, MP4, M4A, M4A (ALAC), M4B, 3GP, APL, AC3, M1V, M4V, MOV, AAC, AMR, AWB, WAV, PCM, LPCM, MP1, MP2, AIF, AIFF, AIFC, SND, WMA, OGG, FLAC
- Photo : JPG, JPE, JPEG, TIFF, TIF, GIF, PNG, BMP
- Video : WMV, ASF, VDR, AVI, XVID, DIVX, FLV, MPG, MPE, MTS, M2TS, M2T, MPEG, SPTS, M2P, M2V, MP2T, MP2P, MPG2, DVR-MS, VOB
- Playlist : M3U, M3U8, WPL, PLS
|
Multimedia Station |
- Supports photo, audio and video
- Image slideshow and rotation
- Automatic and scheduled thumbnail generation for easy browsing
- Display Photo Details from EXIF : Date, exposure time, aperture and more
- Display Audio Details from ID3 Tag : Album cover, title, artist, album and more
- Access authority management
- Multimedia (video and audio) streaming
- Supports cooliris
- Supports web publishing (Facebook, MySpace, MSN Live, Twitter, Plurk and Blogger)
- Share photos by email
- Supported Formats :
- Photo – JPG/JPEG, GIF, PNG
- Audio – MP3
- Video
- Playback : FLV, MPEG-4 Video (H.264 + AAC)
- Transcode : AVI, M4V, MPG/MPEG, RM/RMVB, WMV
- QNAP Exclusive iPhone and Android App : QMobile
|
Photo Station |
- Supported File Formats :
- Photo : JPG/JPEG, GIF, PNG, BMP
- Video : FLV, MPEG-4 Video (H.264 + AAC)
- Image slideshow with background music
- Photo publishing to social websites (Facebook, MySpace, Twitter, Plurk and Blogger)
- Photo sharing by email
|
Music Station |
- Supported Audio Formats :
- MP3, MP4, OGG, WAV, AIFF, AU, FLAC, M4A, APE, AAC
- Local playback with USB speaker or sound card
- Browse other UPnP media servers on local network
- Internet radio (MP3)
- Music alarm (up to 8 Alarms)
- Playback control by QNAP Mobile App : QMobile music remote
|
Download Station |
- PC-less BT, FTP, HTTP download (up to 500 tasks)
- BT Download
- Supports TCP/UDP tracker protocol
- Scheduled download
- Configurable port range
- Bandwidth control
- UPnP NAT port forwarding
- RSS subscription and download (broadcatching)
- Selectable download files
- HTTP/ FTP Download
- Configurable saving directory
- Bulk download with wildcard settings
- RapidShare download support
- QNAP Download Management Software : QGet
- For both Windows and Mac OS
- Manage the download tasks of multiple QNAP NAS remotely over LAN or WAN
|
Surveillance Station |
- Supports 4 IP cameras (sold separately) for network surveillance
- Supports 1 Webcam via QPKG Add-on : QUSB Cam
|
Antivirus |
- Protection against the latest known viruses, Trojans and other threats
- Free virus databases update on manual or scheduled basis
- Multiple scan tasks (max : 64, concurrent : 5) with custom folder selection and scheduled
- Scanning
- Email notification upon task completion or virus detection
- Quarantines or deletes infected files
|
QPKG Center |
- Expands application services by easy online installation
- A wide variety of official and community QPKG* add-ons
- Business
- eyeOS
- GLPI
- Squid proxy server
- Vtiger CRM
- CMS
- Gallery
- Joomla
- WordPress
- Xoops
- Communications
- Download
- MLDonkey
- NZBGet
- pyLoad
- SABnzbdplus
- Transmission
- Entertainment
- Ice Station
- Plex media server
- PS3 media server
- Squeezebox server
- Utilities
- AjaXplorer
- iStat
- Optware IPKG
- phpMyAdmin
- Piwik
- Miscellaneous
- Java runtime environment
- Mono
- Python
- QUSB Cam
- Tomcat and more
|
General |
Temperature |
32 to 104°F (0 to 40°C) |
Relative Humidity |
0 to 90% |
Dimensions |
3.46 x 17.28 x 20.47″ (88 x 439 x 520 mm) |
Weight |
27.60 lb (12.52 kg) |
