Hardware |
CPU |
Intel Atom 2.13 GHz Dual-core Processor |
DRAM |
1 GB RAM (Expandable RAM, up to 3 GB) |
Flash Memory |
512 MB DOM |
Hard Disk Drive |
2.5″ (63.49 mm) or 3.5″ (88.89 mm) SATA x 8 |
Hard Disk Tray |
8 x Hot-swappable and lockable tray |
LAN Port |
2 x Gigabit RJ-45 Ethernet port |
LED Indicators |
Status, LAN, USB, eSATA, Power, HDD 1, HDD 2, HDD 3, HDD 4, HDD 5, HDD 6, HDD 7, HDD 8 |
USB |
- 2x USB 3.0 port (Back : 2) 5x USB 2.0 port (Front : 1; Back : 4)
- Supports USB printer, pen drive, USB hub and USB UPS etc.
|
eSATA |
2 x eSATA ports (Back) |
Performance |
- Reading : 221.8 Mbps
- Writing : 220.8 Mbps
|
Buttons |
Power button, USB One-Touch-Backup Button, Reset button |
LCD Panel |
- Mono LCD display with backlight
- Enter button, Select button for configuration
|
Supply Type |
System warning |
Form Factor |
Tower |
Sound Level |
- Without HDD installed : 40.0 dB
- Stand by : 40.4 dB
- In operation : 40.8 dB (with 8 x 750 GB HDD installed)
|
Power Consumption |
- Sleep mode : 30 W
- In Operation : 59 W
- Power-off (in WOL mode) : 1 W (with 8 x 1.5 TB HDD installed)
|
Power Supply |
- Input : 100-240 V AC, 50-60 Hz
- Output : 350 W
|
Secure Design |
K-lock security slot for theft prevention |
Expansion Slot |
1 (for network or storage expansion) |
VGA |
Reserved VGA interface for maintenance |
Fan |
Two 4.72″ (12 cm), 12 V DC cooling fan |
General |
Temperature |
32 to 104˚F (0 to 40˚C) |
Humidity |
0-95% R.H. |
Dimensions |
7.29 x 11.74 x 9.26″ (185.2 x 298.2 x 235.4 mm) |
Weight |
- Net weight : 7.29 kg (16.08 lb)
- Gross weight : 8.59 kg (18.94 lb)
|
Software |
Operating System |
Embedded Linux |
Supported Operating System |
- Microsoft Windows 2000, XP, Vista (32 or 64 bit),7 (32 or 64 bit), Server 2003 or 2008
- Apple Mac OS X
- Linux and Unix
|
Supported Web Browsers |
- Internet Explorer 7, 8 or later
- Firefox 3 or later
- Safari 3, 4 or later
- Google Chrome
|
Multilingual Support |
Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Norwegian, Polish, Russian, Spanish, Swedish, Turkish |
File System |
- Internal HDD : EXT3, EXT4
- External HDD : EXT3, EXT4, NTFS, FAT32, HFS+
|
Networking |
- TCP/IP (IPv4 and IPv6 : Dual Stack)
- Dual Gigabit LAN with Jumbo Frame
- Multi-IP settings, Port Trunking or NIC Teaming (Modes : Balance-rr, Active backup, Balance XOR, Broadcast, IEEE 802.3ad or Link Aggregation, Balance-tlb and Balance-alb)
- DHCP client, DHCP server
- Protocols : CIFS or SMB, AFP (3.1), NFS, FTP, HTTP, HTTPS, Telnet, SSH, iSCSIand SNMP.
- Network Service Discovery(UPnP, Bonjour)
- Virtual LAN support
- USB Wi-Fi 802.11n adapter support (optional purchase)
|
Network File Sharing |
- CIFS/SMB (Plus DFS Support)
- AFP
- NFS
- FTP
- WebDAV
|
Backup Solution |
- Real-time Remote Replication (RTRR)
- oWorks as Both RTRR server andclient
- oSupports Real-time andscheduled backup
- oSupports encryption, compression and file filter
- USB One Touch Backup (Import or export)
- Apple Time Machine Support with backup management
- Block-level Remote Replication
- oWork as both Rsync server &client
- oSupports encrypted replication between QNAP NAS servers
- Back up to external storage device
- Back up to Cloud Storage (Amazon S3 and ElephantDrive)
|
Security |
- IP filter andpolicybased automatic IP blocking
- Network Access Protection with auto-blocking
- Encrypted access : HTTPS, FTP with SSL or TLS (explicit), SSH or SFTP (admin only), Encrypted Remote Replication (Rsync over SSH)
- CIFS host access control for shared folders
- AES 256-bit volume-based encryption
- Importable SSL certificate
- Instant alert via email, SMS and LCD
|
Disk Management |
- Single disk, JBOD, RAID 0 / 1 / 5 /10/ 5+Hot spare / 6 /10
- Online RAID capacity expansion &online RAID level migration
- Bad Block Scan & HDD S.M.A.R.T
- Global Spare Drive
- AES 256-bit volume-based encryption
- RAID recovery
- Bitmap support
- Supports ISO mounting (via web file manager)
|
iSCSI (IP SAN) |
- iSCSI Target
- oMulti-LUNs per target
- oUp to 256 LUNs
- oSupports LUN mapping & masking
- oSupports SPC-3 persistent reservation
- oSupports MPIO & MC/S
- Virtual Disk Drive (via iSCSI Initiator)
- oStack Chaining Master
- oMax. virtual disk drives : 8
- oStorage plug and play client software to connect to iSCSI Target from PC
|
Server Virtualization & Clustering |
- Supports VMware vSphere (ESX or ESXi 4.x)
- Supports Citrix XenServer (5.6)
- Supports Windows server 2008 Hyper-V & failover clustering
|
Power Management |
- Wake on LAN
- Scheduled power on/off (Max 15 settings)
- Automatic power on after power recovery
|
Access Rights Management |
- Max user accounts : 4,096
- Max groups : 512
- Maxshare folder : 512
- Batch creating users
- Import or export users
- User quota management
- Subfolder permissions support
|
Windows AD Support |
- Domain users login via CIFS/SMB, AFP, FTP and web file manager
- Supports NTLM v2 authentication
|
Web Administration |
- AJAX-based user interface
- HTTP or HTTPS connections
- Alert notification (Email & SMS)
- Smart fan control
- DDNS & MyCloudNAS remote access
- SNMP (v2 & v3)
- UPS support with SNMP management (USB)
- Supports network UPS
- Resource monitor
- Network recycle bin for CIFS or SMB and AFP
- Comprehensive logs (Events andconnection)
- Real-time online user list
- Syslog client
- Firmware update with live update notification
- Backup and restore system settings
- Restore to factory default
|
Applications |
- Web file manager
- Multimedia station
- Download station
- Surveillance station
- Music station
- Photo station
- iTunes server
- UPnP media server
- Apache web server
- MySQL server
- VPN server
- LDAP server
|
QMobile App |
- QMobile for iPhone, iPad, iPod touch, Android devices
- Third party UPnP media player
|
QPKG |
- Web applications
- oJoomla!
- ophpMyAdmin
- oWordPress
- oAjaXplorer
- ovtigerCRM
- oGLPI
- oMagento
- P2P Applications
- oMLDonkey (eMule)
- oSABnzbd+
|
