Meraki MS250-48FP Nigeria

Rating

Meraki MS250-48FP Nigeria

The Meraki MS250-48FP Nigeria is a 24-port cloud-managed stackable enterprise-class access switch with four SFP+ uplinks, support for redundant power supplies for mission critical environments, and IP routing.

Category:

Description

Meraki MS250-48FP Network Switch Nigeria

The Cisco Meraki MS250-48FP Nigeria is a 24-port cloud-managed stackable enterprise-class access switch with four SFP+ uplinks, support for redundant power supplies for mission critical environments, and IP routing. Meraki MS250-48FP Nigeria includes integrated client and layer 7 application visibility, remote troubleshooting tools like live packet capture and cable test. Meraki Network Switch Nigeria is fully cloud-managed via the intuitive, browser-based Meraki dashboard, and includes a rich, out-of-the-box feature for easy configuration and provisioning without need of additional cost and complexity.

The  Meraki MS250-48FP Switch Nigeria provide reliable access switching ideal for deploying in branches and small campuses. With stacking capabilities and 10G SFP+ uplinks on every model, redundancy and performance are guaranteed. Meraki MS250-48FP also supports redundant, field-replaceable power supplies for mission-critical networks. Meraki switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.

Features

  • Gigabit access switching with 24- and 48- port models and optional PoE+ support
  • 4 x 10G SFP+ uplink interfaces on all models
  • Dual stacking interfaces with up to 80G of bandwidth
  • Support for field replaceable, redundant power supplies
  • Non-blocking switch backplane with up to 176 Gbps of switching capacity
  • 6 configurable QoS queues for converged voice, video, and data applications
  • Up to 740 watt PoE budget with PoE+ support and dynamic power allocation for powering APs, phones, cameras, and other PoE-enabled devices
  • Low power consumption, quiet acoustic design, and shallow rack depth options, enabling flexible deployment in wiring closets as well as offices and classrooms
  • Integrated mounting brackets for rack mounting
  • Lifetime hardware warranty and advanced replacement at no additional cost

Cloud Management

The Meraki Cloud Networking architecture enables Plug and Play branch deployments and provides centralized visibility and control across any number of distributed locations. The Meraki MS250-48FP Nigeria is the industry’s cloud managed switch, combining the benefits of cloud-based centralized management with a powerful, reliable access platform. With cloud management, thousands of switch ports can be configured and monitored instantly, over the web. Provision remote sites without on-site IT, deploy network-wide configuration changes, and easily manage campus and distributed networks without training or dedicated staff.

Layer 7 application and client visibility

Meraki MS250-48FP Nigeria features integrated Layer 7 application and client fingerprinting and analysis. Hundreds of applications are automatically identified and reported, from business apps to BitTorrent and YouTube, so administrators can see where resources are spent.

QoS for voice and video

Deploy latency-sensitive applications such as voice and video by guaranteeing network performance. Voice and QoS features such as per-VLAN and protocol-based prioritization, as well as flexible QoS assignments, give intuitive, granular control.

Enterprise security

Extending security down to the port level has never been easier. Meraki MS250-48FP Nigeria integrate seamlessly with enterprise-grade security systems using 802.1x. Define access policies, segregate guest devices, and quarantine entire environments right from the dashboard.

Specifications

Dimensions and Interfaces

  • Physical Dimensions (H x W x D) : 1.72 x 19.08 x 20.42” (4.38 x 48.46 x 51.87cm)
  • Weight : 12.83 lb (5.82 kg)
  • Interface : 48 x 10/100/1000BASE-T Ethernet RJ45 with auto negotiation and crossover detection (auto-MDIX crossover) 4 x SFP+ 10GbE uplink, 2 x stacking ports
  • Switching Capacity :176 Gbps
  • Stacking Bandwidth : 80G (dual interface)

Power Options and Specifications

  • Idle / Full Load Power : 25 / 874 W
  • Available PoE+ Power : 740 W
  • Power Supply Configuration : Hot-swappable
  • Supported Power Supply : 2 x 1025W PSU

Management

  • Managed via the Web with the Meraki cloud management platform
  • Integrated with Meraki Wireless and complete portfolio of IT products and solutions
  • Zero-touch remote provisioning (no staging needed)
  • Detailed historical per-port and per-client usage statistics
  • DHCP, client, and hostname fingerprinting
  • SNMP and SYSLOG support for integration with other network management solutions
  • Automatic firmware upgrades with scheduling control

Remote Diagnostics

  • Email, SMS and Mobile push notification alerts
  • Cable testing and link failure detection with alerting
  • Live remote packet capture
  • Dynamic and interactive network discovery and topology
  • Combined event and configuration change logs with instant search

Stacking

  • Physical stacking of up to 8 switches with 80 Gbps stack bandwidth on all models
  • Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration

Ethernet Switching Capabilities

  • 802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
  • 802.1Q VLAN and trunking support for up to 4,094 VLANs
  • 802.1w, 802.1D Rapid Spanning Tree Protocol (RSTP, STP)
  • Broadcast storm control
  • 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP)
  • 802.3ad Link aggregation with up to 8 ports per aggregate, Multi-chassis aggregates supported on stacked switches
  • Port mirroring
  • IGMP snooping for multicast filtering
  • MAC forwarding entries : 16K on 24-port models, 32K on 48-port models

Security

  • Integrated two-factor authentication for Dashboard management
  • Role-based access control (RBAC) with granular device and configuration control
  • Corporate wide password policy enforcement
  • IEEE 802.1X RADIUS and MAB, hybrid authentication and RADIUS server testing
  • Multi-Domain/Multi-Host/Multi Authentication
  • Port security : Sticky MAC, MAC whitelisting
  • DHCP snooping, detection and blocking, Dynamic ARP Inspection
  • STP Enhancements : BPDU guard, Root guard, Loop guard
  • IPv4 and IPv6 ACLs

Performance

  • Switching capacity : 128Gbps on 24-port models, 176Gbps on 48-port models
  • Forwarding rate : 95.24mpps on 24-port models, 127.98mpps on 48-port models
  • Jumbo frame support (9578 byte Ethernet frame)
  • Flow control support

Layer 3

  • Static routing, OSFPv2
  • Warm Spare (VRRP)2
  • DHCP Relay, DHCP Serve

Power

  • Power input : 100 – 240 VAC, 47-63 Hz
  • Power consumption : 5-1655W

Environment

  • Operating temperature : -5°C to 50°C
  • Humidity : 5 to 95% non-condensing
  • Variable speed fans

Mounting

  • 1U rack-mountable with included rack mount hardware
  • 2-post front mounting options available
  • Desktop-mountable with included feet

Regulatory

  • CE (Europe)

Warranty

Full lifetime hardware warranty with next-day advanced replacement included
