Description

Meraki MG41E Cellular Gateway Nigeria

The Meraki MG41E Nigeria is a Gateway Cellular providing high-speed, always-on reliable network connectivity for business-critical operations and a hybrid workforce through cellular deployments with gigabit primary or backup cellular uplinks. MG41E provides primary cellular connectivity across thousands of sites at once without waiting on broadband or any change in infrastructure, enabling faster business expansion.

Deliver primary gigabit connectivity with Meraki MG41E Nigeria or pair with Meraki MX and SD-WAN to allow for the optimal bandwidth management needed for today’s cloud-first organizations. With gigabit-level backup cellular connectivity, businesses can rely on MG41 for a consistent experience 24/7/365 to increase business uptime and network resilience.

Meraki MG41E Nigeria allows deployment of primary gigabit cellular at sites where there’s no broadband coverage, the carrier coverage is initially unknown, or there’s a varying level of availability and network reliability from multiple regional carriers. The dual SIM gives the flexibility to switch to a better performing carrier network through auto-SIM failover or switch to the other carrier when either of the SIM reaches the data cap.

Features

Hardware

Sleek form factor
x1 CAT 18 Integrated Cellular up to 1.2Gbps
x2 nano (4FF) SIM card slots
x2 GbE ports
Multi-surface mounting bracket for attachment to walls, ceilings, or poles
IP67 rated for environments of all types
Dipole Antenna (included)
x4 External Antennas
x2 Patch Anetnnas (optional)
Supports up to 5 simultaneous carrier aggregation (5CA)
Supports popular bands like B14 (FirstNet), B48 (CBRS), B66 and B71
Supports private LTE

Power

DC or PoE
x2 PoE ports

Use cases

Primary cellular connectivity
Failover cellular connectivity

Cloud-based centralized management

Managed centrally over the web
Zero-touch, self-provisioning deployments
Remote troubleshooting tools
Secure, user-scheduled firmware updates
Remote visibility of key cellular information : IMEI, ICCID, APN, RSRP, RSRQ
Auto-SIM failover

Cloud APIs

All MG configuration settings executable via APIs

Self-configuring, cellular primary

If a certified carrier SIM card is inserted, the MG41 brings up the cellular connection and automatically connects to the Meraki cloud, downloads its configuration, and joins your network.

Industry-leading cloud management

Meraki’s award-winning cloud-management architecture unifies LAN and management under a web-based dashboard and scales easily from small to large multi-site deployments with tens of thousands of devices. The Meraki dashboard provides intuitive yet powerful role-based administration, firmware updates, configuration changes, email alerts, and easy to-audit change logs.

Specifications

Performance

2 Gbps Downlink (DL)/ 150 Mbps Uplink (UL)

Interfaces

2 * PoE IN
LAN interfaces : 2 x GbE
1 x CAT 18 LTE integrated cellular

Monitoring and Reporting

Throughput, connectivity monitoring
Org-level change logs for compliance and change management

Environmental Specifications

Power : 12V/1A, 48-57V DC/0.35A
Operating temperature : -22°F to 122°F (-30°C to 50°C)
Humidity : 5 to 95% non-condensing
IP67 environmental rating
Desktop or wall mount or ceiling mount (all standard mounting hardware included)

Remote Diagnostics

Live remote packet capture
Real-time diagnostic and troubleshooting tools

Management

Managed via the web using the Meraki Cloud Controller
Single pane of glass management of wired and wireless networks
Zero-touch remote deployment (no staging needed)
Automatic firmware upgrades and security patches
Centralized policy management
Org-level two-factor authentication and single sign-on
Role based administration with change logging and alerts

Integrated Cellular

Support for major bands : 2, 4, 5 ,12, 13, 14, 48, 66, 71 *Refer to the datasheet for the full list
2 Gbps Downlink (DL)/ 150 Mbps Uplink (UL)
Additional regulatory information : PTCRB (US), RCM (ANZ, APAC), GCF (EU)

Supported UICC/SIM

2 * external SIM card
