Fanvil X3SP-V2 Nigeria

Rating

Fanvil X3SP-V2 Nigeria

The Fanvil X3SP-V2 Nigeria is a new series of IP phones equipped with a 2,4″ color display and upgraded keys with LED backlighting, allows great flexibility and efficiency of work.

Category:

Description

Fanvil X3SP-V2 PoE VoIP Phone Nigeria

The Fanvil X3SP-V2 Nigeria is a new series of IP phones equipped with a 2,4″ color display and upgraded keys with LED backlighting, allows great flexibility and efficiency of work. High definition audio support, more SIP accounts and EHS headset support make the Fanvil X3SP-V2 IP phone an effective work tool. This IP phone also supports PoE power supply.

With all the necessary VoIP features and other extended features, it provides the high-quality and convenient experience for users at an affordable price. With all the necessary VoIP features and other extended features, Fanvil X3SP-V2 Nigeria provides the high-quality and convenient experience for users at an affordable price.

Features

  • 2 SIP lines
  • HD voice, full duplex speaker
  • PoE enabled
  • Colour LCD 320 x 240
  • EHS support for headsets
  • RJ9 headset port
  • Desktop/wall mount install options
  • Easy installation and configuration
  • High interoperability – compatible with major platforms : 3CX, Elastix, Asterisk, Xorcom, etc.

2.4″ color display and high resolution sound

The new Fanvil X3SP-V2 Nigeria IP phone series has a bright 2.4-inch color display with 320×240 dots resolution for high image quality. Thanks to wideband G.722 and Opus codecs, Fanvil X3SP-V2 IP phone allows you to enjoy crystal clear sound and highly efficient communication.

Various installation options and support for EHS headsets

The EHS wireless headset supported on the new X3SP-V2 series IP phone via the EHS cable enables a wide variety of call handling tasks. The new Fanvil X3SP-V2 Nigeria 2 IP phone can be installed on a desk stand with two different angles or on a wall mount, which is very useful in different office layouts.

PoE-Enabled

The Fanvil X3SP-V2 VoIP Phone comes with dual 10/100Mbs Gigabit Ethernet Ports which are integrated with Power over Ethernet, making it easy to carry out remote configuration and automatic provisioning.

HD Audio

Fanvil X3SP-V2 IP Phone Nigeria is integrated with a full-duplex speakerphone which delivers outstanding audio clarity to its users.

Wide Compatibility

The Fanvil X3SP-V2 VoIP Phone is widely compatible with major professional platforms including Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc.

Wall Mountable

The Fanvil X3SP-V2 Nigeria comes with a flexible stand that can be adjusted into two different angles of 45°  and 50° to offer its users a comfortable viewing angle.

Specifications

Generic

  • 2 SIP Lines
  • HD Voice
  • Handset (HS) / Hands-free(HF) / Headphone (HP) mode (EHS support for Plantronics headsets)
  • Desktop / Wall-mount installation
  • Economical and Environmental friendly package
  • Industrial Standard Certifications : CE/FCC

Call Features

  • Call out / answer / reject
  • Mute / unmute (microphone)
  • Call Hold / Resume
  • Call Waiting
  • Intercom
  • Caller ID Display
  • Call Forwarding (Always/Busy/No Answer)
  • Call Transfer (Attended/Unattended)
  • Call Parking/Pick-up (depending on server)
  • Redial
  • Do-Not-Disturb (per line / per phone)
  • Auto-Answering (per line)
  • Voice Message (on server)
  • Local 3-way Conference
  • Hot Line

Phone Features

  • Phone Accessibility Control by User PIN
  • Intelligent Phonebook (up to 500 entries total)
  • Remote Phonebook (XML/LDAP)
  • Intelligent Contact Number Matching / Filtering
  •  Call log (300 entries total, in/out/missed)
  •  Voice Message Waiting Indication (VMWI)
  •  Network Time Synchronisation
  •  Multi-language support in screen and web UI : English, Chinese (Traditional/Simplified), Japanese, Russian, Italian, Turkish, Germany, Dutch, Spanish, Hebrew, Polish, French etc.

Audio

  • HD Voice Microphone/Speaker (Handset/Hands-free, 0~7KHz Frequency Response)
  • Wideband ADC/DAC 16KHz Sampling
  • Narrowband CODEC : G.711a/u, G.723.1, G.726-32K, G.729AB
  • Wideband CODEC : G.722
  • Full-duplex Acoustic Echo Canceller (AEC) – Hands-free Mode, 96ms tail-length
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer up to 300ms
  • DTMF : In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO

Networking

  • Physical : 10/100Mbps (X3SP-V2), 10/100/1000Mbps(X3G) Ethernet, dual bridged port for PC bypass
  • IP Configuration : Static / DHCP / PPPoE
  • Network Access Control : 802.1x
  • VPN : L2TP (Basic Unencrypted) / OpenVPN
  • VLAN
  • QoS

Protocols

  • SIP2.0 over UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCP
  • PPPoE
  • 802.1x
  • L2TP (Basic Unencrypted)
  • OpenVPN
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR069

RFCs :

  • 354/1321/1350/1769/1889/1890/2131/2132/
    2616/2617/2661/2833/2976/3261/3262/3263/
    3264/3265/3268/3311/ 3489/3711/4346/4566/
    5630/5865

Deployment & Maintenance

  • Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP/OPT66/SIP PNP/TR069
  • Web Management Portal
  • Web-based Packet Dump
  • Configuration Backup/Restore
  • Auto/Manual Online Software Upgrade
  • Syslog

Physical Specifications

  • LCD x1 : 2.4/2.8 inch (320×240) LCD colour screen
  • Keypad : 32 keys, including :
    – 4 Soft-keys
    – 12 Standard Phone Digits Keys
    – 5 Navigation Keys
    – 2 Line keys with tri-colour LED
    – 5 Function key
    – 3 Volume Control Keys, Up/Down/Mute (Microphone)
    – 1 Hands-free
  • HD Hands-free Speaker (0 ~ 7KHz) x1
  • HD Hands-free Microphone (0 ~ 7KHz) x1
  • HD Handset (RJ9) x1
  • Standard RJ9 Handset Wire x1
  • 1.5M CAT5 Ethernet Cable x1
  • RJ9 Phone Jacket x2 : Handset x1, Headphone x1
  • RJ45 Ethernet Jacket x2 : Network x1 (802.3AF POE Class 1 Enabled), PC x1 (Bridged to Network)
  • Main Chipset : Broadcom
  • DC Power Input : 5V/600mA
  • Working Temperature : 0 ~ 40℃
  • Working Humidity : 10 ~ 65%
  • Dual-Functional Back Rack x1 : Desktop Stand / Wall-mount
  • Colour : Black
  • Package Dimensions : 275x215x62mm (W x H x L)
