Fanvil H5W Nigeria

The Fanvil H5W Nigeria is WiFi IP phone with HD audio delivering smoother communication experience with HD audio and no cabling troubles. Fanvil H5W Nigeria supports H.264 video decoding to help owners to view the video image before opening the door

Category:

Description

Fanvil H5W Wi-Fi IP Phone Nigeria

The Fanvil H5W Nigeria is WiFi IP phone with HD audio delivering smoother communication experience with HD audio and no cabling troubles. Fanvil H5W Nigeria supports H.264 video decoding to help owners to view the video image before opening the door. More than a hotel IP phone, it is also suitable for the supermarket, hospital, shopping mall. Fanvil H5W is the IP Phone designed for hotels. With stylish, fresh appearance, excellent voice quality, and matching integrated communication platform, it can become a new generation of hotel intelligent terminal equipment.

Features

3.5”Color Screen Displays Hotel Information

The Fanvil H5W Nigeria Hotel IP phone possesses one 3.5-inch color screen. Hotel managers could DIY the information on the screen from IP phone’s management platform.

Check before Opening the Door

When connected with the SIP door phones, intercoms or camera at the door, Fanvil H5W Nigeria enables you to view the video image of visitors in advance and achieve the remote door unlock.

Wireless, Limitless

Get tired of the messy cables? Connecting to the Network with 2.4G built-in WiFi, Fanvil H5W can be installed anywhere in the room without the limitation of cabling.

Capture Every HD Voice

With the wide codec G.722 and Opus, Fanvil H5W Nigeria can convey every voice during your communications clearly and stably.

Elegant Outlook

Fanvil H5W Nigeria is the IP Phone designed for hotels. With stylish, fresh appearance, excellent voice quality, and matching integrated communication platform, it can become a new generation of hotel intelligent terminal equipment.

Programmable Soft Keys for Service Hotline

Fanvil H5W Nigeria has 6 programmable Soft Keys for the service hotline (Housekeeping, Ticketing, Switchboard, Food and beverage, etc) and the hotel considerate services (Morning call, Voice message, and etc).

Support SIP Hotspot

Fanvil H5W IP phones Nigeria can share one number from the server. When a call comes in, each extension phone will ring together to make sure you won’t miss a call.

Specifications

Generic

  • 2 SIP Lines
  • HD Voice
  • PoE
  • Handset / Hands-free mode
  • External Power Supply(Optional)

Phone Functions

  • Call logs (In/Out/Missed, Max support 600 records in the web)
  • Programmable DSS/soft keys
  • Action URL / Active URI
  • Web dial
  • Dial plan
  • SIP Hotspot
  • Distinctive ring
  • Multicast

Call Functions

  • Call out / Answer
  • Mute / Unmute
  • Call Hold / Resume
  • Speed Dial
  • Redial
  • Auto-Answering
  • Hot Line
  • Customised ring

Audio

  • Wideband ADC/DAC 16KHz sampling
  • Narrowband codec : G.711A/U, G.729AB, iLBC
  • Wideband codec : G.722, Opus
  • Full-duplex hands-free speakerphone with AEC
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG)/ Background Noise Estimation (BNE) / Noise Reduction (NR)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer
  • DTMF : In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO
  • VQM voice quality monitoring

Video

  • Hardware video decoding : H.264/H.265(Optional)
  • Video call resolution : QVGA / CIF / VGA / 4CIF / 720P / 1080P

Network

  • 10/100 Mbps Ethernet
  • IP Mode :IPv4/IPv6/IPv4&IPv6
  • IP Configuration : Static / DHCP / PPPoE
  • Network Access Control : 802.1x
  • VPN : L2TP / OpenVPN
  • VLAN : 802.1P/Q
  • QoS
  • RTCP-XR (RFC3611), VQ-RTCPXR(RFC6035)

Protocols

  • SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCP
  • IPv6
  • PPPoE
  • L2TP
  • OpenVPN
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR-069

Deployment & Maintenance

  • Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIPPNP/TR-069
  • Web management portal
  • Web-based packet dump
  • Configuration export / import
  • Firmware upgrade
  • Syslog

Physical Specifications

  • 3.5-inch (320×480) colour screen
  • Keypad : 26 keys, including :
    – 6 DSS Key
    – 4 Function keys (Hold, Call Transfer, Redial, MWI)
    – 12 Standard Phone Digits keys
    – 3 Volume Control keys, Up/Down/Mute(with red colour LED)
    – 1 Hands-free key
  • MSG indicator (with red colour LED) x1
  • HD Handset (RJ9) x1
  • Standard RJ9 Handset Cord x1
  • RJ9 Port x1 : Handset x1
  • RJ45 Port x2 : Network x1, PC x1 (Bridged to Network)
  • USB Port x1 : Standard A
  • Power : 5V/2A or PoE
  • Power Consumption (PoE) : 1.5W ~ 5.65W
  • Power Consumption (Adapter) : 2.13W ~ 7.46W
  • Working Temperature : 0~45℃
  • Working Humidity : 10~95%
  • Installation : Desktop
  • Colour : Black/white
  • Device Dimensions : 151.7×193.2×131.7mm
  • Gift Box Dimensions : 225x210x125mm
  • Outer CTN Dimensions : 515x435x245mm(8 PCS)
